压锁式线路板支架

材质Material
UL合格之Nylon66(本色),防火等级94V-2,不易老化,绝缘度高。
Nvlon66(natural) conforming to UL,flameproof grade:94V-2,not easy to age, with high insulativity.
用法Usage
免工具、用手装卸容易。使用时先将基板钻孔后将隔离柱固定,再将PC板套入即可。Easy to assemble and disassemble with hand,withouttools.When using, firstly drill the base plate, and fix the isolatingpost,then setinto the PC plate.
特点 Feature
双锁式、固定力强,插入省力,不易脱套Double lock type,with strong fixing force.Easy to insert and noteasy to press off.
用途 ApplicationPC板固定用。PC plate is fixed to use.


关键词:

所属分类:

产品附件:

PROSUN

咨询热线:

联系我们
  • 产品描述
    • 商品名称: 压锁式线路板支架

    材质Material<br> UL合格之Nylon66(本色),防火等级94V-2,不易老化,绝缘度高。<br> Nvlon66(natural) conforming to UL,flameproof grade:94V-2,not easy to age, with high insulativity.<br> 用法Usage<br> 免工具、用手装卸容易。使用时先将基板钻孔后将隔离柱固定,再将PC板套入即可。Easy to assemble and disassemble with hand,withouttools.When using, firstly drill the base plate, and fix the isolatingpost,then setinto the PC plate.<br> 特点 Feature<br> 双锁式、固定力强,插入省力,不易脱套Double lock type,with strong fixing force.Easy to insert and noteasy to press off.<br> 用途 ApplicationPC板固定用。PC plate is fixed to use.<br>
